Construction elements

Columns, trusses, ring beams, slabs... every main element of steel, timber and reinforced concrete structures explained with a diagram, typical dimensions and mistakes to avoid.

Footings (pad & strip)
Footings (pad & strip)
Reinforced concrete spread transferring the column load (pad footing) or wall load (strip footing) to the soil. Everything starts here: a failed foundation can never be fixed.
Read the sheet →
Reinforced concrete column
Reinforced concrete column
Vertical load-bearing member: concrete takes compression, longitudinal bars take bending, and stirrups stop the bars from buckling and the concrete from bursting. The trio is inseparable.
Read the sheet →
RC beam & lintel
RC beam & lintel
The beam spans openings and carries floors or walls; the lintel is its little sister above doors and windows. Bottom bars take bending tension, stirrups take shear.
Read the sheet →
Bond beams & tie columns
Bond beams & tie columns
The safety belt of a blockwork house: bottom ring beam on the foundations, vertical tie columns at corners and openings, top ring beam under the roof. They stitch the masonry into a solid box resisting settlement, wind and earthquakes. The most neglected element of self-built sites.
Read the sheet →
Solid slab vs hollow block slab
Solid slab vs hollow block slab
Two ways to build a floor: the solid slab (full-depth reinforced concrete, heavy but simple) and the hollow block slab (joists + blocks + topping, lighter and cement-saving). Typical choice in Africa: hollow blocks for storeys, solid for short spans and wet areas.
Read the sheet →
RC staircase
RC staircase
Inclined slab (waist) on which the steps are cast. The waist works as a bending slab between its two supports: its main bars run along the slope, on the lower face.
Read the sheet →
Retaining wall
Retaining wall
L-shaped wall holding back earth on sloping ground: the soil weight on its base stabilizes it against the thrust. Drainage behind the wall is as vital as the rebar — trapped water doubles the thrust.
Read the sheet →
Rebar detailing: bars, stirrups, cover
Rebar detailing: bars, stirrups, cover
The golden rules common to all reinforced concrete: clean well-positioned bars, sufficient laps, correct hooks and cover guaranteed by spacers. 80% of RC defects come from poorly detailed or poorly placed rebar.
Read the sheet →
Beam-and-block floor slab
Beam-and-block floor slab
A precast beam-and-hollow-block floor gives an economical slab with little formwork: the joists carry the hollow blocks, then a reinforced concrete topping ties everything together.
Read the sheet →

Quick guide: common building-site questions

How many blocks per m² of wall?

About 12.5 blocks of 40 × 20 cm per m², plus 5% breakage. For a 30 m² wall plan around 390 blocks. Read the sheet →

Is a CEB house strong?

Yes, if the soil is tested, properly stabilized and protected from water (plinth, render, roof overhang). CEB is used for multi-storey buildings with ring beams. Read the sheet →

What is the maximum span of a 16+4 beam-and-block floor?

About 4.5 m under ordinary residential loads. Beyond that, use 20+5 or a solid slab, after an engineer's advice. Read the sheet →

How many sheets for a 100 m² roof?

Count the real area (including slope, about 105-115 m² for 100 m² on plan) plus 10% for laps and offcuts. Read the sheet →

Tiles or steel sheets?

Steel sheets are faster and cheaper; tiles last longer and stay cooler but are heavier and need a stronger frame. Read the sheet →

How many tiles for 20 m²?

20 m² plus 10% for cuts, i.e. 22 m². With 60 × 60 cm tiles (0.36 m²), you need about 62 tiles. Read the sheet →
